EV & Energy Storage High-Voltage Cable Assembly Manufacturer
Linkssor manufactures high-voltage cable assemblies for electric vehicle battery packs, power distribution units, traction motors and stationary energy storage systems. Assemblies use orange HV-rated cable with shielded or sealed ring-terminal and connector terminations, produced under IATF 16949:2016 manufacturing controls with 100% electrical and insulation testing.
High-voltage assemblies are unforgiving: one marginal crimp becomes a thermal event. We treat the crimp as a controlled process with cross-section verification on every lot, and we build the insulation and shielding stack around the application's voltage class, not around what is cheapest.
Typical applications
Battery pack internal and pack-to-PDU cable assemblies
PDU, BMS and junction box HV harnesses
Traction motor and inverter three-phase assemblies
On-board charger and DC-DC connections
Stationary / containerised energy storage racks
Charging inlet and charging pile internal harnesses
Specification range
Voltage class
Up to 1,000 V DC / 600 V AC typical; application-specific to customer requirement
Cable
Orange HV-rated XLPE or silicone insulated cable, shielded (braid/foil) options
Terminals
Sealed ring terminals, compression lugs, ultrasonic-welded busbar connections
IP67 / IP6K9K target with boots, grommets and heat-shrink sealing systems
Testing
100% continuity and pin-out; insulation resistance, dielectric withstand (HIPOT) available
Traceability
Lot traceability on cable, terminal and seal; test record per unit
Standards
IATF 16949:2016 manufacturing; customer-specified workmanship criteria on request
Configuration options
Heat-shrink identification sleeves with part number and date code
Cable-routing clips, brackets and conduit
EMI shielding with drain wire or 360° shield termination
Custom connector development with self-locking and waterproof mechanism
Voltage and temperature sensing sub-branches
Product examples
Sealed HV cable assemblies with ring terminalsRing-terminal cable bundleGround strap assembly setGround strap with dual ring terminalsSealed circular connector assembly
Questions on this family
Do you supply HV cable assemblies with HIPOT testing?
Yes. Insulation resistance and dielectric withstand testing can be specified per assembly, with the test record tied to the unit serial or lot.
Can you develop a custom waterproof connector?
Yes. Our Shenzhen technology entity holds a utility model patent (ZL 2025 2 1004104.X) for a waterproof connector with a self-locking mechanism, and we support application-specific connector development.
Which customers have you served in the EV and energy storage sector?
We have delivered programmes for battery and powertrain suppliers in China including pack and powertrain specialists. Customer references can be shared under NDA.
Certificate scope: our IATF 16949:2016 certificate covers manufacturing of wire harness and excludes product design under Clause 8.3. Specifications shown are the range we manufacture, not a warranty of suitability for a specific application.
